Chemical corrosion resistance slurry pump

We are producing Chemical corrosion resistance slurry pump with silicon nitride bonded silicon carbide (Si3N4-SiC). There are many good characteristics of ceramic slurry pump, such as abrasion resistance, corrosion resistance etc. Now the parts are continually provided for coal power generation, non-ferrous foundry, mining and others.
The corrosion and abrasion resistance of ceramic slurry pump parts are highly exceed ones made by high chrome alloy. The abrasion resistance of Si3N4-SiC material is 3.13 times as wearable as Cr15Mo3. However the weight of Si3N4-SiC material is only 1/3 of alloy parts.

Si3N4-SiC(silicon nitride bonded silicon carbide)is a kind of inorganic nonmetallic materials.
Its wear-resisting performance is 3.13times of Cr15Mo3 with Mohs hardness 8.9, only after Diamond and Cubic Boron Nitride. Compare with similar products, our ceramic density is about 5% higher than others, and double flexural strength higher at normal temperature.

ModelMax PowerMaterialsClear Water Performance
(kw)LinerImpellerCapacity (m3/h)Head (m)
1.5/1B-H15CeramicCeramic12.6-28.86-68
2/1.5B-H15CeramicCeramic32.4-726-58
3/2C-H30CeramicCeramic39.6-86.412-64
4/3C-H30CeramicCeramic86.4-1989-52
4/3D-H60CeramicCeramic97.2-1989-53
6/4D-H60CeramicCeramic162-36012-56
6/4E-H120CeramicCeramic162-36012-56
8/6E-H120CeramicCeramic360-82810-61
